PPGI Sheet stands for Pre-painted Galvanized Iron Sheet, which is a type of steel sheet that is coated with a layer of paint or polymer film in order to protect the underlying metal from corrosion and improve its aesthetic appearance.
PPGI Sheet is commonly used in industries such as construction, automotive, and appliances. It is known for its excellent durability, resistance to weathering, and ease of maintenance. Additionally, it offers a wide range of colors and patterns, making it a popular choice in architectural and decorative applications.
PPGI Sheet is typically made from galvanized steel, which is coated with a primer and then painted with a topcoat of high-quality paint or polymer film. The coating process involves a series of steps, including cleaning, pretreatment, priming, and painting, in order to ensure a high-quality finish and long-lasting protection against corrosion and weathering.
PPGI Sheet is available in a variety of thicknesses and sizes to suit different applications and requirements. It is also available with different types of coatings, including polyester, silicone, and PVDF, each with their own unique properties and advantages.
Overall, PPGI Sheet is a versatile and highly durable material that offers excellent protection against corrosion and weathering, while also providing a wide range of aesthetic options for various applications.
| Grade | DX51D, SGCC, SGCH, SGLCC, SGLCH,Q195 |
| Thickness | 0.12-1.5mm |
| Width | 762mm/680,670,660,655,650mm 9 waves |
| 914mm/815,810,790,780mm 11 waves | |
| 1000mm/930 915,910,905,900,880,875mm 12 or 14 waves | |
| OR OEM | |
| Length | 1.5-12meters or as client’s request |
| Zinc coating | 30-275g/m2 |
| Coating thickness | Top side 15-25 micro; Back side 5-15 micro |
| Normally, Top 17-25micro, Back 5-7 micro | |
| Surface | High Glossy |
| Paints | Nippon, Akzo Nobel, Winter, Pingyuan depends on clients’ request |
